Heavy Duty Cantilever Rack

JT RACKING is divided into single and double cantilever racks. And it is composed of the main part and accessories.

Category：

Cantilever Racking
Browse number：

207
Release time：

2024-09-24 14:03:29

INQUIRY

Detailed Description

Heavy Duty Cantilever Rack

Heavy Duty Cantilever Rack

Main part

① Column

② Arm

③ Base

④ H Bracing

⑤ X Bracing

Accessory

⑥ Wire Mesh Deck

⑦ Steel Panel

⑧ Support Bar

⑨ Bracket

⑩ Guide Rail

C/C COLUMN

Heavy Duty Cantilever Rack

ARM

Heavy Duty Cantilever Rack

ACCESSORIES

Heavy Duty Cantilever Rack

Distribution of X and H Bracing

X bracing is used in different type of cantilever racks. The function of bracing is to connect two columns together for a cantilever rack unit. Meanwhile, they strengthen the stability of the rack.

Distribution of X and H Bracing X bracing is used in different type of cantilever racks. The function of bracing is to connect two columns together for a cantilever rack unit. Meanwhile, they strengthen the stability of the rack.

Distribution of H Bracing and D Bracing

Featured Arm Technology

Cantilever Arm is a very important part of cantilever rack and the selection of arms takes a great influence on the whole storage solutions. JT RACKING offers the arms made with square tube and cold rolled profiles, with locked pin to fix to the column and adjusted up and down the columns.

Arm can be welded to different positions on the connector according to customized load requirements. Straight arm, standard arm, and inclined arm are available.

JT RACKING

JT RACKING pivot arm technology is very effective and strong. If impact occurs, the pivoting arm swings upwards so protecting the arm and preventing structural damage.
